PCX-PROX/INT

Description

Key Features

Proximity tag reader to set/unset the system
Works as set/unset controller
Proximity Tag or Card Reader
Backlit symbol indications for alert, alarm, tamper, fault and unset
2 inputs or 2 outputs, or 1 input and 1 output
Complies with EN50131-1

Features
Certification
Technical Specification
Codes & Options
Downloads

Product Features

Convenient system setting and unsetting

The internal proximity reader is a quick and easy way to allow multiple people to set and unset a system away from the main security control panel.

Proximity tag reader to set or unset the system; also works as a set or unset controller
Can be used with proximity tags or cards
Backlit symbol indications for alert, alarm, tamper, fault and unset
Can be set to have either 2 inputs or 2 outputs, or 1 input and 1 output

PCX 46 APP

PCX External Prox Reader

Proximity Tag

EN 50131–1:2006+A1:2009 | EN 50131–3:2009 | EN50131–6:2008 | PD6662:2010

PCX-PROX/INT - EN Certification - 10.212-11856 - Denmark

Technical Specification

Setting devices technical characteristics

Integrated prox reader	Yes
System status display	Yes
Tamper protection	Front and rear

Inputs & outputs

Onboard wired inputs	2
Outputs on board	1

Environmental and operating features

Storage temperature	-20C to +60C
Nominal operating temperature	-20C to +60C
Physical dimensions (H x W x D)	97 x 40 x 23mm

Electrical & battery

Operating voltage	12Vdc Nominal (9-15 Volt DC Range)
Quiescent current consumption	<30mA Quiescent. <90mA Maximum
Supply protection	Reverse polarity protected

Certifications and warranty

Security Grade	Grade 3
Environmental class	II
EN Certificate	EN-50131-1
Certification type	Self-certified
Electrical conformity	CE
Warranty	2 years

Codes & Options

Product Codes & Options

PCX Proxi Internal Proximity Reader

PCX-PROXI/EX

Catalogues and Flyers

PCX-PROX/INT Datasheet

Product Compliance Certificate

PCX-PROX/INT - EN Certification - 10.212-11856 - Denmark
