PCX-RIX8+PSU
Description
Key Features
- RS485 Expander
- 8 Double Pole or Double EOL Inputs + 3EOL
- 4 Transistor Outputs
- Integrated 2.5A power supply
- Complies with EN50131-1
Hover over images to zoom
Product Features
Expand your systems potential
The PCX-RIX8+PSU allows you to expand the security system with an additional 8 inputs and runs off its own intelligent power unit. Whatever the need or requirement, add 8 wired devices to the hybrid control panels to seamlessly adapt the system to suit.
Robust metal housing
The unit comes in a metal case with front and rear tamper for added peace of mind that the system is secure.
Wiring options
The PCX-RIX8+PSU Double Pole or Double EoL (End of Line) Zone Expander accepts wiring for each of the 8 inputs. ALSO SUPPORTS 3EOL.
Resistor values
For Double Pole wiring you will need to set the control panel in 4K7/2K2 mode (4K7 resistor for alarm and 2K2 resistor for tamper).
Input and output expanders technical characteristics
Metal housing |
Yes |
Tamper protection |
Yes |
Integrated RS485 repeater for extending data bus range |
Yes |
Inputs & outputs
Wired EOL inputs |
8 |
Wired double pole inputs |
8 |
Total inputs |
8 |
Outputs on board |
4 |
Environmental and operating features
Certified operating temperature |
-10 to +40C |
Nominal operating temperature |
-10 to +40C |
Physical dimensions (H x W x D) |
390mm x 310mm x 80mm |
Weight |
1062g |
Electrical & battery
Intergrated power supply |
2A |
Battery capacity |
700mA (8A to 17A) |
Battery supply protection |
Reverse polarity protected |
Battery low voltage protection |
10.5v low voltage cut off |
Internal battery charger |
800mA Continuous, 13.68V nominal (fold-back current limited) |
Recharge time |
<24 hours |
Mains supply |
230v (220-240v) AC Max 250mA |
Operating voltage |
11-15v DC |
Current limit |
400mA |
Certifications and warranty
Security Grade |
Grade 3 |
Environmental class |
II |
EN Certificate |
EN50131-3:2009 | EN50131-1:2006+A1:2009 | PD6662:2010 |
Certification type |
IMQ |
Certificate number |
CA12.01431 |
Electrical conformity |
CE |
Warranty |
2 years |
Product Codes & Options
PCX-RIX8+PSU Input Expansion Module with PSU
FPPCX-RIX8+PSU
