KX10DTP-WE

Description

(English) The KX10DTP-WE is a versatile two-way wireless detector combining microwave and PIR tech for reliable intrusion detection in challenging conditions. Requiring both sensors to trigger, it minimizes false alarms. With pet immunity for animals under 20kg, it offers security while pets move freely in the property.

Key Features
  • (English) Pet immunity up to 20kg
  • (English) Longer battery life with instant two-way device control (ITDC)
  • (English) Highly secure 868MHz transceiver FM technology
Features

Product Features

(English) The KX10DTP-WE is a flexible two-way wireless detector that utilises microwave and PIR technology to ensure intruder catch performance is maintained even when the environment is hostile and there are fluctuations in temperature.

(English) The dual technology system needs both sensors inside the KX10DTP-WE to be triggered before the alarm is sounded reducing the risk of false alarms. It is a pet immune detector, meaning that animals less than 20kg can roam around the property without fear of the alarm being triggered.

(English) Signal Strength Indicator (SSI)

(English) One of the key advantages of implementing of the SSI technology is to allow the installer to view the wireless transmission signal strength on both the control panel and wireless devices in real time.

(English) Blue wave technology

(English) This technology further enhances the detector’s immunity to infra-red noise in the environment. BWT comprises of some key components:

The new 3D optics system enables perfect focussing of the infra-red signal onto the pyro-electric sensor. This allows BWT to clearly identify the positive and negative signal edges.
Digital temperature compensation digitally adjusts the detectors sensitivity to maintain performance in fluctuating environments.
Powerful software embedded into a microprocessor is used to process the received information from the pyro-electric sensor. The result of this combination is lower infra-red signal noise amplification and therefore better immunity.

(English) Instant two way Device Control (ITDC)

(English) The ITDC technology enables instant wake up and instant sleep of each device on the system, allowing continuous communication between the control panel and wireless devices while preserving battery power. This technology not only provides installers with total control of each device, but also gives users peace of mind that they have a reliable and secure wireless system.
– Ensuring that all wireless detection devices know when the system is armed and disarmed.
– Ensuring that they are awake as soon as the system is armed.

(English) Two Way Wireless Technology

(English) Each wireless device on the Enforcer system, including movement detectors is a transmitter and a receiver. The wireless technology used on the Enforcer system holds a significant advantage over one way and some two way wireless products currently available on the market due to its advanced and innovative features.

(English) Sealed optics

(English) Protects from possible infestation from insects, shields air movement in front of the pyro-electric sensor and protects against adverse reflections from inside the detector housing.

(English) ABS plastics 3mm

(English) Polished finish, reduces electrostatic interference on the PIR sensor.

Related products & accessories
Suportes KX
View Product
UR2-WE Two-way Wireless Universal Receiver
View Product
Certificação
Especificação técnica

Características técnicas dos detectores

(English) Two-way wireless technology

(English) Yes

(English) Blue Wave technology

(English) Yes

(English) Automatic sensitivity

(English) Yes

(English) Digital temperature compensation

(English) Yes

(English) Tamper protection

(English) Front and rear

(English) Separate LED indication

(English) Microwave, PIR, Alarm

(English) Signal Strength Indicators (SSI)

(English) Yes

(English) 3 microwave frequencies to avoid interference

(English) Yes

Características técnicas dos detectores

(English) Signal Strength Indicators (SSI)

(English) Yes

(English) Instant two way device control (ITDC)

(English) Yes

(English) Pyronix high security two way wireless data encryption protocol (TDE)

(English) Yes

(English) Pyronix intelligent jamming detection

(English) Yes

(English) 868MHz transceiver FM technology

(English) Yes

(English) One push to learn

(English) Yes

(English) Tranmission method

(English) Fully encrypted rolling code

(English) Transmission range

(English) 300m in open space

Características técnicas dos detectores

(English) Maximum range

(English) 10m

(English) Dual technology

(English) Yes

(English) Animal immunity

(English) 25kg

(English) Detection speed

0.3- 3.0m/s

(English) Detection zones

(English) 52

(English) Detection planes

5

Montagem

(English) Wall mounted

(English) Optional brackets available

(English) Ceiling mounted

(English) Optional brackets available

(English) Optimum coverage height

1.8 - 2.4m

(English) Certified mounting height

2.4m

Recursos ambientais e operacionais

(English) Storage temperature

(English) -20C to 50C

(English) Certified operating temperature

(English) -10C to 40C

(English) Nominal operating temperature

(English) -10C to 50C

(English) Physical dimensions (H x W x D)

(English) 117 x 69 x 59mm

Elétrica e bateria

(English) Battery type

(English) 2 x 3.0V CR123A

(English) Battery life

(English) Up to 2 years

(English) Battery voltage

(English) 3.0V

Certificações e garantia

(English) Security Grade

(English) Grade 2

(English) Environmental class

II

(English) EN Certificate

EN50131-2-4:2008, EN50131-5-3:2005+A1:2008, PD6662:2010

(English) Certification type

IMQ

(English) Certificate number

CA12.01484

(English) Electrical conformity

CE

(English) Warranty

(English) 2 years
Codes & Options

Códigos e opções de produtos

(English) KX10DTP1-WE
(English) KX10DTP1-WE
SAP: 361300017
(English) KX10DTP2-WE
(English) KX10DTP2-WE
SAP: 361300018
(English) KX10DTP3-WE
(English) KX10DTP3-WE
SAP: 361301134
